Duplex vs Triplex vs Fourplex in Vancouver: Key Differences and How to Choose
When it comes to multiplex development in Metro Vancouver, the classic adage of “less is more” doesn’t always apply. More units doesn’t automatically mean better results. Because while higher density can increase income potential, it can also add complexity and risk to a project.
The right choice depends on a number of factors such as zoning, lot constraints, budget, and long-term goals: understanding the key differences between a duplex, triplex, and fourplex will help you decide what best aligns with your specific property, goals, and budget.
Duplex vs Triplex vs Fourplex in Vancouver: Key Differences
It’s not just a number - see the structural difference between two, three, and four units, according to the City of Vancouver bylaws:
What Is a Duplex?
Referred to as a “two-family dwelling”, a duplex is constructed as two separate housing units, typically designed as a single structure.
What Is a Triplex?
With three separate housing units, a triplex is built as a single structure, or even multiple structures based on the property lot and design, and subject to approval from the City of Vancouver.
What Is a Fourplex?
Similar to a triplex, these four separate housing units can be made up of a single structure, or even multiple structures as well.
Duplex vs Triplex vs Fourplex in Vancouver: Cost, Complexity, and Risk
More units tend to mean less flexibility: each additional unit built comes with additional costs, complexities, and risk to consider.
Density and Layout Implications
A duplex is relatively straightforward, with a minimum site area of 306 m2, allowing for simple stacked or side-by-side designs. A triplex or fourplex, on the other hand, can be more complex. While the minimum site area is the same as a duplex, this means that the homes themselves are more constrained; higher unit counts can also determine the number of bedrooms required.
Rental Income Potential
More units, of course, leads to more rental opportunities. Data from the Canada Mortgage and Housing Corporation (CMHC) indicates that the average 2-bedroom home is renting for about $2,400 and is anticipated to rise to $2,750 by 2027. CMHC also notes that units with more than 2 bedrooms (such as triplex or fourplexes) could earn up to 20 to 50% more revenue.
While a newly constructed multiplex unit may attract and command a slightly higher rent, it is wise to consider operating expenses such as professional property management and future repair and maintenance costs when projecting your revenue stream; up to 5 to 10% of your monthly rental income.
Financing
CMHC provides financing for all three property types, but the terms and conditions for these insured mortgages differ as the unit count rises.
Known as “Standard Multi-Unit Insurance”, or MLI, duplexes are treated in a relatively straightforward manner similar to a residential mortgage. A triple or fourplex development will likely face more red tape in the form of demand for rent rolls, engineer reports, and longer pre-approval periods.
What Determines How Many Units You Can Build in Vancouver?
A number of factors are at play when determining what multiplex project works best for your unit. You can check out our full Multiplex Feasibility Checklist, but here are the key considerations to take into account:
Zoning and Permitted Uses
The City of Vancouver R1-1 Zoning Bylaw provides guidelines on zoning requirements and permitted uses. You can check out their Digital Zoning Map to check details on an exact address.
Lot Size, Frontage, and Building Envelope
The minimum lot size for duplexes, triplexes, and fourplexes is the same: you need at least 3,300 sq.ft to be eligible to build. With a floor space ratio, or FSR, of 0.70, you can build up to 70% of total living space based on your lot’s size.
Servicing and Infrastructure Requirements
In what we’ve referred to as “The Hidden Feasibility Factor”, water, sewer, and storm servicing capacity plays a critical role in determining how many units you can build. Height also matters: the maximum allowance for new multiplexes is three storeys tall, two storeys for a rear building.
How to Choose the Right Multiplex for Your Goals
Choosing the right development project for your specific property is a subjective decision, driven not only by financial considerations but also emotional ones.
Based on Lifestyle and Privacy Priorities
For those prioritizing multi-generational living, more units means more people but possibly less privacy.
As design layouts become more complex, that increases the number of shared walls and common spaces, which also leads to more potential noise from neighbours. Side-by-side designs can help create a sense of more distinct spaces with separate entrances and exterior spaces.
Based on Rental Income and Long-Term Strategy
If rental income is your main goal, then maximizing density opportunities while considering your long-term revenue strategy is the way to go.
Three-bedroom units are in moderate demand, especially in family-oriented neighbourhoods such as Kitsilano, Mount Pleasant, or Point Grey, but two-bedroom units attract a broader and faster-moving pool of qualified tenants.
Based on Budget and Risk Tolerance
Duplexes are the most fiscally conservative development project with the lowest entry point
Frequently Asked Questions
1. What is the difference between a duplex, triplex, and fourplex?
While a duplex (two units) can typically be given outright approval based on the City of Vancouver R1-1 bylaw, a triplex (three units) or fourplex (four units) may require conditional approval.
2. Duplex vs triplex: which is better if I plan to live in one unit?
This is a subjective decision that depends on your comfort level and living requirements; if you prefer privacy, a duplex may be a better option.
3. Triplex vs fourplex: is the extra unit worth it?
If your primary goal is rental income, then a fourplex is worth the investment. If you’re an owner-occupier, it has less financial value but provides flexibility for intergenerational living options.
4. Can every Vancouver lot support a fourplex?
No, as there are specific requirements for both triplex and fourplex properties that differ from duplex developments.
5. Does adding more units increase multiplex permit complexity?
Yes, each additional unit adds a level of complexity to the permit process, particularly when it comes to site eligibility, bedroom requirements, and approval timelines: 6 to 12 months for a triplex or fourplex compared to 3 to 6 months for a duplex.
Final Thoughts
No two properties are the same. Even with general guidelines, from feasibility to occupancy, every Vancouver multiplex development will look different from the next.
